Toro Groundsmaster® 7210

Toro Groundsmaster® 7210

The Groundsmaster® 7210-D is a zero turn rotary mower that is rugged enough to be called a Groundsmaster. Powerful Yanmar 36.8hp (27.4kW), 3-cylinder, liquid cooled diesel engine combined with decks that use the industry’s toughest spindle assembly, match power and durability for commercial operators. Convert the Groundsmaster 7210-D from mowing into a powerful snow removal machine in less than 4 hours with the PolarTrac® system.

Configuration Options:

Groundsmaster 7210 w/mowing deck
Groundsmaster 7210 with Cab and Polar Trac system

Groundsmaster® 7200 Models can be configured with one of the following decks:

Deck Options:
72″ side discharge
72″ rear discharge
72″ Guardian Recycler and Fine Cut Guardian kits

Quick Quote

Name(Required)

More Info

• Tight wheel base, power steering and individual steering brakes allow for expert handling and increased productivity.
• A Rollover Protection System (ROPS), complete with seat belt, comes standard for operator protection in the case of accidental rollovers and tipovers. In situations where sufficient vertical clearance is not available, such as loading on an enclosed trailer, the ROPS can be temporarily unlocked and folded down.
• The electric-clutch deck engagement is smoother than the manual systems and the new air ride seat suspension glides over the bumps.
• The discharge deflector on the 72" (183 cm) side discharge deck is constructed of durable 5/16" (8 mm) thick rubber and allows for close trimming without damaging chute or landscape structures. Patent-pending design provides exceptional dispersion.
• The high-strength one-quarter inch (6 mm) thick heat-treated alloy steel blades resist flexing and abrasive wear. The result is a crisp cut time after time.
• The deck shells are constructed from high-strength 7-gauge welded steel, for greater durability and long life.
• The cast iron spindle housings feature greater stability and strength, providing longer deck and spindle life.
• Maximize your productivity with a wide variety of attachments and accessories including the Polar Trac® System. The system converts the • Groundsmaster 7200 into a snow removal machine complete with two rubber tracks and a climate controlled cab.

Specifications
Air Filter: Remote-mounted 5" Donaldson® air cleaner
Armrests: Standard
Battery:12V
Blade Style/Type: Rotary
Cab Unit: Polar Trac Kit
Cooling System Description: Rear-mount, cross-flow radiator with 6.5 fins per 1” (25 mm), 8 U.S. qt. (7.6 L) capacity
Cup Holder: Standard
Drivetrain: Diesel
Electrical System: 12-volt battery (BCI No. 24) 540CCA, 55 amp internal regulated alternator charging @ 3150 rpm
Engine Cooling: Liquid Cooled
Fuel / Power Source: Diesel / Biodiesel
Fuel Capacity: 11.5 U.S. gal. (43.5 L)
Fuel Economy: 1.1 gallon/hr (4.8 liter/hr)
Fuel Filter: Fuel filter/water separator
Gauges/Instrumentation: InfoCenter™: LCD display shows gauges, alerts/faults, service reminders, electrical system diagnostics. Indicates, coolant temp, intake temperature, low oil pressure, alternator, engine hours, engine rpm, hydraulic oil temperature, voltage.
Ground Clearance: Capable of climbing 8" (20.3 cm) curbs
Ground Speed - Forward: 0 - 12.5 mph (0 - 20 km/h)
Ground Speed - Reverse: 0 - 8.5 mph (0 - 13.7 km/h)
Hydraulic Fluid Capacity: 3.5 U.S. gal. (13.2 L)
IntelliDash™ Capable: No
Interlocks: Tractor neutral, operator presence, parking brake, PTO on, auxiliary hydraulics on, high temp (PTO shuts down but engine still running), over temp (engine shuts down)
Lighting: Optional
Main Frame/Chassis: Structured steel tube and high strength steel plate welded construction, with tie down loops on each corner
Max Slope Angle: Refer to operator's manual
Oil Capacity: 5.5 U.S. qt. (5.2 L)
Oil Cooler Description: External spin-on oil filter and high flow fixed fan
Optional Accessories: Road Light Kit, 12V Power Port Kit, Slope Sensor Kit, SMV Sign, Jack Stand Kit, Semi-Pneumatic Tire Assembly (front caster wheel), Lug Tire
Parking/Service Brakes: Service: Twin levers with dynamic braking through hydrostatic transmission. Parking: Hand actuated brake lever with two 10.25" diameter disc brakes mounted on the rear wheel motors.
Power Steering: Yes
Power Train (Engine Description): Yanmar® 3-cylinder common-rail, liquid-cooled, diesel with EGR and diesel particulate filter (DPF), 36.8 hp (27.4 Kw) rated @ 3000 rpm, 80 ft-lbs. @ 1950 rpm, displacement 1642 cc., EPA Tier IV Final compliant
PTO Clutch: Hydraulically actuated wet multi-disc clutch
Safety/Operator Safety: Two-post foldable ROPS standard, optional ROPS certified heat-only cab available
Seat: Two piece, high back cushion seat with drain hole, deluxe low profile suspension, adjustable for operator weight, seat back angle, seat fore/aft position, armrest height, retractable seat belt
Starting: Key Start
Steering System Description: Adjustable twin sticks with high performance KYB® hydraulic dampers. Rev/N/Forward, located on sides of operator.
Tires - Front: 24" x 12" - 12", 6-ply, Turf Tire
Tires - Rear: 15" x 6" - 6", 4-ply
Tool Box: Standard
Traction Drive: 2WD
Traction Drive (System): Two independent closed-loop circuits. One pump/motor controlling left side forward, neutral, and reverse, and one pump/motor controlling right side forward, neutral, and reverse. Pumps are variable displacement piston type with slippers and full stroke capacity of 18 cc/rev.
