• Outstanding 360-degree visibility
• Outstanding reach and lift height

Specifications:
Air Filter: Two-stage, heavy-duty, remote
Cooling System: Liquid Cooled
Dump Angle: 46.3 degrees
Dump Height (cm): 162.8
Dump Height (inches): 64.1
Engine Make: Kubota
Engine Model: D1803
Fuel Tank (gallons): 18.3
Fuel Tank (liters): 69.3
Fuel Type: Diesel
Ground Clearance (cm): 16
Ground Clearance (inches): 6.3
Ground Pressure: 5.3 psi
Ground Speed Forward (mph): 5.4
Ground Speed Foward (km/h): 8.6
Ground Speed Reverse (km/h): 8.6
Ground Speed Reverse (mph): 5.4
Hinge Pin Height (cm): 250.4
Hinge Pin Height (inches): 98.6
Hydraulic Flow: 21.5 gpm (81.4 lpm) each pump
Hydraulic Flow Auxilary: 21.4 gpm
Hydraulic Pressure: Auxillery:3000 psi; traction: 4350 psi
Loader Arms: Radial
Manufacturer's Gross HP Rating (HP): 49.6
Manufacturer's Gross HP Rating (kW): 37
Max Operating Height (cm): 162
Max Operating Height (inches): 63.9
Oil Capacity (liters): 7
Oil Capacity (quarts): 7.4
Overall Height w/bucket (cm): 172.2
Overall Height w/bucket (inches): 67.8
Overall Height w/o bucket (cm): 17.2
Overall Height w/o bucket (inches): 67.8
Overall Length w/bucket (cm): 347.7
Overall Length w/bucket (inches): 136.9
Overall Length w/o bucket (cm): 250.9
Overall Length w/o bucket (inches): 98.8
Overall Width w/bucket (cm): 139.7
Overall Width w/bucket (inches): 55
Overall Width w/o bucket (cm): 139.7
Overall Width w/o bucket (inches): 55
Rated Operating Capacity* (kg): 907
Rated Operating Capacity* (lbs): 2000
Reach – Fully Raised (cm): 66.2
Reach – Fully Raised (inches): 26.1
Reservoir Capacity (gallons): 15.25
Reservoir Capacity (liters): 57.7
Track Length (inches): 162.2
Track Length(cm): 411.9
Track Width (cm): 29.9
Track Width (inches): 11.8
Tracks: Sprocket-drive, 6 road wheels per side
Traction: Dual Hydrostatic Pump
Weight (kg): 2844
Weight (lbs): 6270
Wheelbase (inches): 53.7
