Specifications

• Patented 4-Paw Independent Four-Wheel Drive
• 2-Pump Hydraulic System
• Easy-to-reach 4-stick fingertip hand controls

Specifications:
Air Filter: Two-stage, heavy-duty, remote
Cooling System: Air Cooled
Displacement (cc): 674
Displacement (cu. in.): 41
Dump Angle: 34 degrees
Dump Height (cm): 119
Dump Height (inches): 47
Engine Make: Kohler
Engine Model: Command Series CH23
Fuel Tank (gallons): 11.2
Fuel Tank (liters): 42.4
Fuel Type: Gasoline
Ground Clearance (cm): 14.7
Ground Clearance (inches): 5.8
Ground Speed Forward (mph): 3.7
Ground Speed Foward (km/h): 6
Ground Speed Reverse (km/h): 6
Ground Speed Reverse (mph): 3.7
Hinge Pin Height (cm): 167.6
Hinge Pin Height (inches): 66
Hydraulic Flow: 10.8 gpm high-flow hydraulic circuit, 4 gpm low-flow hydraulic circuit
Hydraulic Flow Auxilary: 13.8 gpm
Hydraulic Pressure: 3250 psi
Loader Arms: Radial
Manufacturer's Gross HP Rating (HP): 25
Manufacturer's Gross HP Rating (kW): 18.6
Max Operating Height (cm): 231.6
Max Operating Height (inches): 91.2
Oil Capacity (liters): 1.9
Oil Capacity (quarts): 2
Overall Height w/bucket (cm): 123.7
Overall Height w/bucket (inches): 48.7
Overall Height w/o bucket (cm): 123.7
Overall Height w/o bucket (inches): 48.7
Overall Length w/bucket (cm): 157.5
Overall Length w/bucket (inches): 62
Overall Length w/o bucket (cm): 157.5
Overall Length w/o bucket (inches): 62
Overall Width w/bucket (cm): 102.8
Overall Width w/bucket (inches): 40.5
Overall Width w/o bucket (cm): 88.9
Overall Width w/o bucket (inches): 35
Rated Operating Capacity* (kg): 233
Rated Operating Capacity* (lbs): 515
Reach – Fully Raised (cm): 71.1
Reach – Fully Raised (inches): 28
Reservoir Capacity (gallons): 17
Reservoir Capacity (liters): 64
RPM: 3600
Weight (kg): 710
Weight (lbs): 1567
Wheelbase (inches): 28
