• The crankshaft, tine arms and frame are perfectly aligned allowing for superior performance and long life. With its fast, efficient performance and innovative design, the deep-tine aerators are able to run smoothly at all depths, relieving pressure-packed soil with superior hole quality.
• There are many coring and solid tines available to cover a wide variety of cultivation practices.
• View the Toro Titan Tines Guide & Catalog
• All of the deep-tine models utilize a standard 3-point hitch hook-up and are powered from the PTO.
• The leverage of the aerator allows the weight to be placed directly over the point of impact, enabling lightweight units to do heavyweight jobs while reducing shock and wear and tear on the machines.
• There are multiple positions available to adjust the soil fracturing movement of the tines. This allows you to adjust and control this motion to your desired application.
• These robust machines are capable of withstanding extreme aeration conditions. The heavy-duty design includes an oversized gearbox, heavy-duty bearings, crank arms and chains, allowing you to operate in the toughest conditions.

Specification
Aeration Type: Deep
Forward Hole Spacing: 2.5" - 4" (64 - 102 mm)
Lift System: Standard 3-point.
Maximum Operating Depth (Working Depth): 1" - 10" (25 - 250 mm)
Maximum PTO Speed: 400 - 500 rpm
Number of Tine Heads: 8
Operating Speed: 1.5 - 2.5 mph (2.41 - 4.02 kph)
Operating Width (Working Width): 73" (1.85 m)
Optional Accessories: Rear Roller Kit (09953)
Productivity: 48,000 sq. ft. / hour (4,460 sq. m / hour)
Recommended Tow Vehicle Requirement: 25 - 35 hp (18.6 - 26.1 kW) with minimum 1,800 lb. (817 kg) lift capacity
Weight: 1,655 lbs. (750 kg)
