• X-Flow shut-off technology is factory installed and holds back 99% of water that would be wasted to a compromised head
• Pressure regulating – factory installed regulator operates at a standard 30 psi to prevent misting and water waste
• Zero-flush seal prevents water waste at start up, allowing more heads to be installed on same line
• Ratcheting riser feature for easy and reliable arc adjustment
• Less visible, reducing damage from exposure or vandals.
• Built into the riser and restricts water loss by 99% if the nozzle is removed or damaged, eliminating potential erosion or safety concerns. Allows for “dry” nozzle and filter-replacement or maintenance, while the system is running.
• Maintains constant 30 psi (2,1 Bar) psi outlet pressure, which minimizes misting and fogging caused by pressures above 30 psi (2,1 Bar).
• Robust retraction spring and enhanced seal material ensures positive pop-up and retraction on all 570Z models.

Specifications
Body Style: Side Inlet Option
Cap Diameter: 2" (50 mm)
Flow: 0.05-4.5 GPM
Inlet: 1/2" (1.3 cm) NPT female threaded
Maximum Operating Pressure: 75 PSI
Operating Pressure: 20-75 PSI
Pop-Up Height: 2", 3", 4", 6", 12" (50, 76, 100, 150, 300 mm)
Radius: 2'-26' (0.6 - 7.9 m)
Recommended Operating Pressure: 30 PSI (2.1 BAR)
