Toro Vista 4 Lithium

Toro Vista 4 Lithium

Built for work and designed for comfort, Toro Vista provides transportation across any property with ease. Vista is available in 4-, 6-, and 8-passenger models. The polar white body and assortment of accessories allow for easy customization no matter the venue. Toro Vista is the perfect choice for any campus, event space, resort, and more. Impress your guests with quick and convenient transportation in the Toro Vista.

Quick Quote

Name(Required)

More Info

• No need to worry about cable adjustments with the automatic parking brake.
• The heavy-duty rigid frame of each shuttle size is specifically designed to handle the anticipated weight.
• Each machine can easily be branded with decals, wrapped, or painted, due to the use of TPO plastic in the body panels.
• Independent suspension, plenty of leg room and ample storage provide a relaxing experience on longer rides.
• Easily view speed, battery level (lithium-ion models), fault codes and other key information on the LCD screen located on the dashboard.
• The rear seating section easily folds down to provide a flat surface for baggage and other cargo during transport.
• HyperCell™ battery technology optimizes Vista’s performance and run-time

Specifications
Battery: Two HyperCell lithium-ion batteries standard, option to add an additional battery
Charger: On-board high efficiency 900W smart charger
AC input voltage 100-240VAC
AC input Frequency 50/60 Hz
Max input Current 13.4 A
Electric Motor: Brushless high-torque AC Induction Motor with 5.0 kW continuous power
Frame: Welded steel with A-coat primer and powder coat
Fuel / Power Source: Battery
Gauges/Instrumentation: Display: Battery level indicator, estimated charge time, gear indicator, speedometer, diagnostics/fault codes.
Dash: USB power port, headlight switch, on/off/neutral ignition key switch, forward/reverse switch, horn switch, turn signal switch (optional), hazard switch (optional), beacon switch (optional), two-cup holders, storage compartments.
Ground Clearance: 8.5” (21.6 cm) at the front with no operator
6.2” (15.7 cm) at the rear with no operator
Ground Speed - Forward: 16 mph standard (25.75 km/h), adjustable from 5-19 mph (8-30.58 km/h)
Height Without Roof: To top of steering wheel: 47.5” (121 cm)
With Roof: To top of canopy: 73.9” 188 cm)
Lights: Standard LED Headlights
Optional Accessories: Canopy, folding windshield, turn signals, beacon, side mirrors, rear view mirror, wide angle mirror, wink mirror, cargo bed (light duty).
Overall Width: 44” (112 cm)
Parking/Service Brakes: Service Brake: 4-wheel hydraulic disc
Parking Brake: Automatic parking brake
Product Length: 109” (277 cm)
Starting: Pedal Start
Steering System Description: Rack and pinion
Suspension - Front: 4-wheel independent suspension with adjustable coil over shocks
Suspension - Rear: 4-wheel independent suspension with adjustable coil over shocks
Total Vehicle Capacity: 1,010 lbs. (458 kg) total
(All totals include 200 lbs. (91 kg) operator and 200 lbs. (91 kg) for each passenger, load, accessories, and attachments.)
Vehicle Configuration: 4-passenger
Weight: 890 lbs. (403 kg) including the required canopy kit
Wheelbase: 65.5” (166 cm)
