Carryall 500 LI-ION [Traction Unit Only – No Attachments Included]

Carryall 500 LI-ION [Traction Unit Only – No Attachments Included]

Carryall 500 LI-ION [Traction Unit Only - No Attachments Included]

$11,609.60

The Carryall 500 showcases unparalleled versatility and rugged durability, establishing itself as the favored choice for a multitude of jobs, day in and day out.

With a rustproof, aircraft-grade aluminum frame, chassis, and cargo box, along with best-in-class ergonomics, the Carryall 500 is the perfect solution for your industrial and
commercial jobs.

Turf Star Western - Contact Form

Get Quick Quote

Thank you for your submission! We'll be in touch soon.
Please correct the errors below and try again.
Please enter your first name
Please enter your last name
Please enter a valid email address
Please enter your phone number
Please select an option
Please select a region
Please enter your ZIP code
You must agree to be contacted
Please complete the CAPTCHA

More Info

Power
Engine: 48-volt AC
Horsepower: 7.4hp (5.5kW) rated; Peak 21.4hp (16kW)
Batteries: Vanguard Lithium-Ion
Charger: High Frequency DeltaQ 650W (upgrade to 900W optional)
Speed Range: 5-19 mph (8-31 kph)

Steering & Suspension
Steering: Self-adjusting Rack and Pinion
Front Suspension: Independent leaf spring w/dual hydraulic shocks
Turning Radius: 119 in. (302.2 cm)
Ground Clearance: 5.6 in. (14.2 cm)

Brakes
Brakes: 4-wheel Mechanical Drum
Park Brake: Foot Operated, Multi-lock

Body & Tires
Body and Finish: ArmorFlex™ with automotive paint/clearcoat
Tires: 20 x 10-10, 6-ply

Dimensions & Weights
Overall Length: 118 in. (299.7 cm)
Overall Height: 47.1 in. (119.6 cm)
Wheelbase: 78.1 in. (198.3 cm)
Curb Weight: 951 lbs (431.4 kg) [Li-Ion]
Bed (LxWxH): 44.2 x 47.5 x 10.5 in (112.2 x 120.6 x 26.6 cm)
Bed Load Capacity: 800 lbs. (362.8 kg)
Towing Capacity: 1,500 lbs (680.3 kg)
Total Payload Capacity: 1,200 lbs (544 kg)

Additional information

Fuel

The Carryall 500 showcases unparalleled versatility and rugged durability, establishing itself as the favored choice for a multitude of jobs, day in and day out.

With a rustproof, aircraft-grade aluminum frame, chassis, and cargo box, along with best-in-class ergonomics, the Carryall 500 is the perfect solution for your industrial and
commercial jobs.
